WLL are indicated in the most constraining situation, hence a 90° angle position
Temperature up to +250°C
This product can be supplied with a works certificate, a 3.1 material certificate and/or EC Declaration of Conformity
Code
|
WLL
(kg)
|
Torque value
(Nm)
|
Weight
(kg)
|
|
105 363
|
400
|
6,5
|
0.43
|
|
105 364
|
700
|
13
|
0.44
|
|
105 365
|
1000
|
22
|
0.46
|
|
105 366
|
1300
|
35
|
0.47
|
|
105 367
|
1600
|
55
|
0.52
|
|
105 368
|
2000
|
80
|
0.54
|
|
105 369
|
2500
|
110
|
0.59
|
|
302 306
|
3000
|
150
|
1.88
|
|
300 282
|
4000
|
190
|
1.93
|
|
302 659
|
5000
|
280
|
1.96
|
|
300 394
|
6300
|
380
|
2.03
|
|
303 069
|
7000
|
520
|
5.28
|
|
301 813
|
10000
|
600
|
5.35
|
|
304 201
|
10000
|
870
|
5.45
|
|
302 178
|
12500
|
1000
|
5.56
|
